Florence

O-ring mounted balance seals

Technical features

• Single seal
• Balanced
• Bi-directional
• To DIN 24960
• Multiple or wave spring

Operating limits

• P = 348 PSI
• T = -95 to 320°F
• V = 65 ft/s

Description	Materials
Primary rings	silicon carbide, ceramic, carbon graphite, stainless
Mating rings	silicon carbide, carbon graphite
Secondary seal	NBR, EPDM, Viton
Metal parts	Stainless 304

Product description

Multi Spring, O-ring design, unitized construction, flexible design compensates for shaft misalignment for high performance and longer seal life. Also available in a balanced design.

Available products

• Florence 1 (FL1)
• Florence 2 (FL2)

Stationary Seats

• US7 (standard)
• US9 (carbon only)
• US8 (carbide face shrink-fitted)
• US3, US5, US10 (carbon only)

product detail [pdf: 155.30 KB] complete catalog [pdf: 5.71 KB]
